Typhoon Resistance Aluminium Patio Sliding Doors
Product Overview
- Top hung ball bearing with smooth sliding feel
- Weather seals provide high-degree weatherproofing & acoustic performance
- Retractable flyscreen available for interior or exterior installation
- Configurations: 220, 330, 321, 431, 550, 532, 660, 633, 752, 743 etc.
- Heavy duty design accommodating up to 3m height
- Glass thickness accommodating from 6.38mm to 19mm
- Laboratory tested and certified to comply with AS2047 & CSA standards
- Acoustic (up to max STC 39) & WERS energy rated configurations
Technical Specifications
| Name / Model |
Typhoon Resistance Aluminium Patio Sliding Doors |
| Standard / Certification |
Comply with AS2047 |
| Deflection Test |
3000 Pa |
| Water Resistance Test |
900 Pa |
| Ultimate Strength Test |
4500 Pa |
| Structural Glazing |
Comply with AS1288 |
| Glass Options |
Low-E, Frosted/Obscure, Tinted (Grey/Blue/Green); Double Toughened (5+12A+5, 6+12A+6); Triple Glazed (5+6A+5+6A+5mm); Laminated (6.38mm, 10.38mm, 10.76mm) |
| Hardware Options |
Australian Doric, German Siegenia/Roto, Top Domestic Brands |
| Surface Finish |
Powder Coated (AS 3715 standard), Electrophoresis, Fluorocarbon, Anodizing, Wood Grain |
| Guarantee Period |
10 Years |
| Wall Type Compatibility |
Double Brick, Brick Veneer, Concrete, Wooden Frame, Steel Structure |
| Subframe Options |
Angles, Timber Reveals, Sub-head, Sub-sills available |
System Options
Option 1: Super System (Thermal Break)
Thermal break system based on awning and high-performance designs, engineered for optimal U-value efficiency and superior energy ratings.
Option 2: Standard System (Non-Thermal Break)
Non-thermal break sliding door system designed for high structural strength, water penetration resistance, and everyday commercial & residential applications.
Certifications & Standards
- Approved by Australian Window Association, SAI Global, and TUV.
- Fabricated strictly according to Australian standard AS2047.
- Glass options fully comply with AS2208 & ANSI Z97.1 safety glass standards.
- Certified member under the Window Energy Rating Scheme (WERS).
Manufacturing & Quality Control
With over 10 years of industry experience, our production line offers an extensive range of high-performance aluminium window and door systems designed for modern residential and commercial applications.
Key Advantages:
- 10-Year product warranty across standard series
- Audited production facilities adhering to AS2047, AS2208, and AS1288
- Extensive global export experience serving residential and commercial projects
Packaging & Protection
Step 1
Wrap window corners with heavy-duty corrugated board and tightly secure with protective film.
Step 2
Position units onto heavy-duty iron steel pallets capable of carrying up to 2.0 T loads (10-15 units/pallet).
Step 3
Secure all units to pallets using steel bars and screws, wrapping the entire assembly with dust/waterproof film.
Step 4
Load containers via forklift using protective air bags between pallets to prevent shifting during ocean transport.
Frequently Asked Questions
Are these sliding doors certified to AS2047 standards?
Yes, all patio sliding doors comply fully with the AS2047 standard. Additionally, glass options meet AS2208, UL, and EN standards for safety and structural integrity.
What is the typical manufacturing lead time?
Production generally takes 38 to 45 days after deposit confirmation and shop drawing approval, allowing sufficient time for high-precision profile extrusion and custom assembly.
Can dimensions and designs be fully customized?
Yes, custom sizing, panel configurations, color finishes, and glass specifications can be tailored to meet your exact architectural requirements.
What surface finishes and colors are available?
Options include powder coating (compliant with AS 3715), anodizing, electrophoresis, fluorocarbon, and wood grain textures. Color selection can be made from Colorbond, RAL, or physical samples.
How are products packaged to prevent ocean shipping damage?
Doors are wrapped in protective film and heavy corrugated board, locked onto iron steel pallets with steel straps, and stabilized with container air bags for 100% safe transport.
What hardware brands are available for these doors?
We offer Australian Doric hardware, German premium brands (Siegenia / Roto), as well as top-grade domestic hardware options depending on project budget and preference.
