Superhosue 20 Years Industry Experience High Energy Efficiency NFRC Narrow Frame Aluminium Casement Window Aluminium windows
1 / 5
Superhosue 20 Years Industry Experience High Energy Efficiency NFRC Narrow Frame Aluminium Casement Window Aluminium windows
50 Years Industry Experience High Energy Efficiency NFRC Narrow Frame Aluminium Casement Window
Product Overview
Each column has many different options and customers can combine the way they like to customize their own personalized 50 years industry experience high energy efficiency narrow frame windows and doors.
Technical Specifications
Profiles
6063-T5 high quality thermal break aluminium profile, thickness 1.4-1.6 mm
6063-T5 high quality non-thermal break aluminium profiles, thickness 1.4-1.6 mm
Single toughened glazing: 3/4/5/6/8/10/12/15/19/21/6.38/11.76mm
Laminated glazing: 5mm+0.76+5mm, 5mm+0.38+5mm
Hardware
German brand: Roto, Siegenia, Geze
Australian brand: Doric
Chinese brand: Kinlong, Zhenjiang
Mesh
Stainless steel security mesh
Aluminium security mesh
Fiberglass flyscreen
Retractable flyscreen
Finish
Powder coating
Anodized
Electrophoresis
Wood grain
Fluorine carbon coating
We provide professional suggestions on profile and glazing adoption if you are purchasing windows or doors for the first time. Different regions have different climatic characteristics, and the treatment on profile or glazing should be customized to meet diversity, impacting the longevity of windows or doors as well as energy absorbing & saving performance.
Frequently Asked Questions (FAQ)
1. What is spectrally selective glazing?
A coated or tinted glazing with optical properties that is transparent to some wavelengths of energy and reflective to others. Typical spectrally selective coatings are transparent to visible light and reflect short-wave and long-wave infrared radiation.
2. What is insulated glass?
This term applies to two or more panes of glass separated by insulation at the edges and air in the centre to provide greater thermal efficiency to a window.
3. What is gas filled glass?
An inert gas, usually argon, is sealed between the panes of glass in a window instead of air. Gas is a better insulator than air, increasing the thermal value of the window.
4. What is AS2047 standard and what performance tests are involved?
AS2047 is the mandatory minimum specification for windows and doors used in Australia, including compliance to the Glass Standard AS 1288. The following performance tests are undertaken to verify product performance claims:
AS 4420.2 Deflection Test: Positive and negative wind pressures are applied to the face of the window to test the maximum deflection under wind load.
AS 4420.3 Operating Force Test: Verifies that an opening sash is capable of opening and closing without undue effort.
AS 4420.4 Air Infiltration Test: Tests air leakage to ensure energy and acoustic efficiency.
AS 4420.5 Water Penetration Resistance Test: Ensures no water leaks through the window into the building.
AS 4420.6 Ultimate Strength Test: Applies positive and negative wind pressures of at least 1.5 times the design wind pressure to ensure structural integrity under unusual wind conditions.
5. What quality warranty is provided for these windows and doors?
Products come with a 10-year quality guarantee. If any window or door issue occurs during the warranty period, exchange support for a new unit is available under warranty policy terms.
6. How do I choose the right window configuration for my climate region?
Different regions possess unique climatic characteristics. Customizing profile thermal breaks, finish types, and specialized glazing options (such as Low-E, double toughened, or gas-filled glass) ensures optimal energy efficiency, noise reduction, and maximum product longevity.
For more information about 50 years industry experience high energy efficiency NFRC narrow frame aluminium casement windows, please feel free to inquire.
